Instrument manufactured by:
CanNeed-ACPRC-100
Automated Capper for Pull Ring Cap
Automated capper for pull-ring caps on glass bottles — PLC-controlled, 1000–5000 N compression range, ±0.5% FS accuracy for beer and cap-factory seal testing.
Request a quotation
Technical specifications
| Detection Object | Beer/Wort/Malt/Microorganisms, End/crown cap/tab cap/screw cap/claw opening cap |
| Test Items | Beer physical and chemical/foam/saccharification power |
| Testing Occasions | laboratory |
Purpose:
The CanNeed-ACPRC-100 Automated Capper for Pull Ring Cap is a high-precision sealing device engineered for glass bottles and pull-off caps. Ideal for the beer industry and cap manufacturing facilities, this automated capper is essential for sealing tests, PU tests, and rigorous experimental applications. By utilizing advanced mechanical structures and intelligent control systems, the device ensures precise cap compression and zero leakage, significantly enhancing production quality and testing efficiency.
Benefits:
- Automatic and efficient capping: Features a PLC intelligent control system with precise pressure settings for one-button operation.
- Pressure adaptive control: High-precision sensors adjust capping force in real-time to ensure perfect alignment across various cap specifications.
- Visual debugging: An intuitive touchscreen interface allows for real-time pressure monitoring and parameter customization.
- Robust design: Constructed with a stainless steel frame featuring a separated electrical and pressurizing station for maximum operational safety.
Technical parameters:
- Compression range: 1000N～5000N
- Accuracy: ±0.5%FS
- Resolution: 1N
- Sealing speed: ~20s per cycle
- Measurement range: Sample diameter 60–100mm, bottle neck inner diameter 27mm, sample height 100–300mm
- Power supply: 220VAC/50Hz
- Air supply: 4-6 bar dry compressed air
- Operating temperature: 0℃～40℃
